Remote Debugging your AI Agents Using Chrome DevTool MCP on Cloud IDEs

Posted
Remote Debugging your AI Agents Using Chrome DevTool MCP on Cloud IDEs
Remote Debugging your AI Agents Using Chrome DevTool MCP on Cloud IDEs
By Amulya Bhatia 6 min read

Cloud IDEs and sandboxes often can’t launch a full Chrome. But the Chrome DevTools MCP server lets LLM tools do real browser actions (navigate, trace performance, inspect network/console, run JS) if it can attach to a Chrome instance. The trick: attach to a Chrome you run outside the sandbox via a secure tunnel—then use Gemini CLI to issue natural-language tasks. In this post, I’ll be using Firebase Studio as the cloud IDE, but the pattern applies to any environment with Gemini CLI and network access.

What we’ll build

1
2
3
4
5
6
7
8
9
10
11

Gemini CLI (Firebase Studio)
        |
   (MCP: chrome-devtools)
        |  --browserUrl=https://<PUBLIC_BASE>  → GET /json/version
        |  ...then connect to WSS /devtools/browser/<id>
        v
   [Node “shim” proxy on your machine]
        |  - rewrites Host: 127.0.0.1
        |  - rewrites webSocketDebuggerUrl in /json/version to your tunnel host
        v
   Chrome (headless) with CDP 127.0.0.1:9222

Why the shim? The MCP server reads webSocketDebuggerUrl as-is from /json/version. Chrome always advertises ws://127.0.0.1:9222/.... In a sandbox, dialing that fails. Our shim rewrites the JSON so the MCP server dials wss://<your-public-host>/devtools/browser/<id> instead — through your tunnel.

Prerequisites

  • A Firebase project (for Hosting; any simple site will do).
  • Firebase Studio workspace with Gemini CLI.
  • Node.js on your machine (to run the shim).
  • Google Chrome (or Chromium) on your machine.
  • A tunneling tool: ngrok or Cloudflare tunnel. There are other solutions for exposing local services - pick your favorite.

Step 0 — (Optional) A tiny “buggy” page to analyze

Here’s a minimal page you can deploy as public/index.html:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

<!doctype html><meta charset="utf-8">
<title>MCP Debug Demo</title>
<input id="q" placeholder="Type (e.g. chicken)…">
<button id="jank">Force Jank</button>
<pre id="log"></pre>
<script>
let reqs=0, leaks=0;
const log = (...a)=>document.getElementById('log').textContent += a.join(' ')+'\n';
async function search(t){ if(!t) return;
  reqs++; log('fetching', reqs);
  const r = await fetch('https://dummyjson.com/recipes/search?q='+encodeURIComponent(t));
  await r.json();
}
function heavy(){ let s=0; for(let i=0;i<3e7;i++) s+=i%3; log('jank done'); }
const q=document.getElementById('q');
q.addEventListener('input', (e)=>{
  // intentionally bad: new scroll listener each input + no debounce
  window.addEventListener('scroll', ()=>{ let s=0; for(let i=0;i<30000;i++) s+=Math.sqrt(i); });
  leaks++; log('leaks', leaks);
  search(e.target.value);
});
document.getElementById('jank').onclick = heavy;
</script>

Deploy with firebase deploy --only hosting and note your URL https://<project-id>.web.app.

Step 1 — Start Chrome with the DevTools protocol on your machine

1
2
3
4
5

# macOS (adjust for Windows/Linux as needed)
"/Applications/Google Chrome.app/Contents/MacOS/Google Chrome" \
  --remote-debugging-port=9222 \
  --headless=new \
  --user-data-dir=/tmp/mcp-chrome

Sanity check:

1

curl http://127.0.0.1:9222/json/version  # should return JSON w/ webSocketDebuggerUrl

Step 2 — Expose it with a tunnel

We need two things:

  1. Chrome must see an allowed Host header (IP or localhost).
  2. The DevTools WebSocket must pass through.

Start ngrok with Host header rewrite:

1

ngrok http 9222 --host-header="127.0.0.1:9222"

Verify from anywhere (including Firebase Studio terminal):

1
2

curl https://<YOUR_NGROK_HOST>/json/version
# Expect JSON (Host-header error = wrong flags)

Step 3 — Add the tiny shim that rewrites /json/version

Create a folder on your machine:

1
2
3

mkdir -p ~/cdp-shim && cd ~/cdp-shim
npm init -y
npm i http-proxy express

Create server.js:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47

// Minimal CDP shim: rewrites webSocketDebuggerUrl to your public host
const express = require('express');
const httpProxy = require('http-proxy');
const http = require('http');

const UPSTREAM = 'http://127.0.0.1:9222';
const PUBLIC_HOST = process.env.PUBLIC_HOST; // e.g. my-tunnel.ngrok-free.app
if (!PUBLIC_HOST) { console.error('Set PUBLIC_HOST to your tunnel host'); process.exit(1); }

const app = express();
const proxy = httpProxy.createProxyServer({ target: UPSTREAM, ws: true, changeOrigin: false });

// 1) Rewrite /json/version to swap scheme+host in webSocketDebuggerUrl
app.get('/json/version', (req, res) => {
  const reqUp = http.request({ host: '127.0.0.1', port: 9222, path: '/json/version',
    headers: { Host: '127.0.0.1:9222' } }, (up) => {
    let body = ''; up.setEncoding('utf8');
    up.on('data', c => body += c);
    up.on('end', () => {
      try {
        const j = JSON.parse(body);
        const path = new URL(j.webSocketDebuggerUrl).pathname; // /devtools/browser/<id>
        j.webSocketDebuggerUrl = `wss://${PUBLIC_HOST}${path}`;
        res.set('content-type', 'application/json; charset=utf-8');
        res.end(JSON.stringify(j));
      } catch (e) { res.statusCode = 502; res.end(String(e)); }
    });
  });
  reqUp.on('error', e => { res.statusCode = 502; res.end(String(e)); });
  reqUp.end();
});

// 2) Everything else → proxy straight through (incl. WS upgrades)
app.use((req, res) => {
  // Ensure Chrome accepts upstream Host:
  req.headers.host = '127.0.0.1:9222';
  proxy.web(req, res, { target: UPSTREAM });
});

const server = app.listen(3000, '127.0.0.1', () =>
  console.log('CDP shim on http://127.0.0.1:3000 (PUBLIC_HOST=%s)', PUBLIC_HOST)
);

server.on('upgrade', (req, socket, head) => {
  req.headers.host = '127.0.0.1:9222';
  proxy.ws(req, socket, head, { target: UPSTREAM });
});

Run it:

1

PUBLIC_HOST=<YOUR_NGROK_HOST> node server.js

Update ngrok to tunnel the shim (port 3000), not 9222:

1
2
3

ngrok http 3000
# Your public base is now https://<YOUR_NGROK_HOST>
curl https://<YOUR_NGROK_HOST>/json/version    # JSON, with wss://<YOUR_NGROK_HOST>/devtools/browser/<id>

WebSocket sanity:

1
2

# Optional: require('ws') or use wscat
npx wscat -c wss://<YOUR_NGROK_HOST>/devtools/browser/<id>   # should connect

Step 4 — Point Gemini CLI (Firebase Studio) at the tunnel

Create or edit .gemini/settings.json in your workspace:

1
2
3
4
5
6
7
8
9
10
11
12
13
14

{
  "mcpServers": {
    "chrome-devtools": {
      "command": "npx",
      "args": [
        "chrome-devtools-mcp@latest",
        "--browserUrl=https://<YOUR_NGROK_HOST>",
        "--headless=true",
        "--isolated=true",
        "--logFile=.gemini/chrome-mcp.log"
      ]
    }
  }
}

Restart the Gemini shell and run /mcp. You should see chrome-devtools with a healthy tool list (navigate_page, list_pages, evaluate_script, list_network_requests, performance_* …).

Note: /mcp only lists tools. The first real action (like new_page or navigate_page) will trigger the /json/version fetch and then the WSS attach. Watch your ngrok logs to confirm both.

Step 6 — Runtime analysis on your Firebase app

Find network spam

Open https://<project-id>.web.app. Emulate Slow 3G. Focus #q, type chicken, wait 2s, then list_network_requests. Count calls to dummyjson.com/recipes/search and explain duplication.

Prove event-listener leak

Type soup in #q, then list_console_messages filtering “added scroll listener”, and evaluate_script returning window.__scrollListenerCount. Summarize what’s wrong.

Capture jank & get insights

performance_start_trace → click the “Force Jank” button → after 3s performance_stop_trace → performance_analyze_insight. Report long tasks & suggestions.

Troubleshooting (copy-paste fixes)

  • “Disconnected (0 tools cached)” Ensure Node ≥ 22 in your Studio environment; restart Gemini after editing .gemini/settings.json.

  • QUIC handshake timeouts with Cloudflare Force HTTP/2 (TCP) instead of QUIC (UDP): cloudflared tunnel --protocol http2 --url http://127.0.0.1:9222

  • “Host header is specified and is not an IP address or localhost.” Your tunnel must send Host: 127.0.0.1 upstream.

    • ngrok: --host-header="127.0.0.1:9222"
    • Cloudflare named tunnel: originRequest.httpHostHeader: 127.0.0.1

  • 307 on WebSocket handshake Something is redirecting (Access login, path normalization). Disable Access for this host, or use ngrok; ensure you dial wss://<host>/devtools/browser/<id> exactly.

  • You only see GET /json/version, no WSS That’s precisely why we added the shim: MCP read ws://127.0.0.1:9222/... and tried to dial it locally. Use the shim and point --browserUrl at the shim’s public base.

Appendix: Windows commands

Chrome

1
2

& "C:\Program Files\Google\Chrome\Application\chrome.exe" `
  --remote-debugging-port=9222 --headless=new --user-data-dir=$env:TEMP\mcp-chrome

Shim

1
2
3
4
5

mkdir cdp-shim; cd cdp-shim
npm init -y
npm i http-proxy express
setx PUBLIC_HOST "<YOUR_NGROK_HOST>"
node server.js

ngrok

1

ngrok http 3000

That’s it! You now have a repeatable pattern to drive real, runtime Chrome debugging from a cloud workspace using Gemini CLI + Chrome DevTools MCP, even when the workspace can’t run Chrome itself.
